Page 7
4/21/2004
REF #
DESCRIPTION
PART NO.
COMMENTS
1
AXLE SPINDLE 2X12 (Q888)
560-178D
2
SEAL (CR16286)
816-398C
3
SEAL SLEEVE (CR081071)
816-396C
4
INNER CONE, JL69349
822-198C
5
INNER CUP JL69310
822-197C
6
GREASE ZERK STRAIGHT 1/4-28
800-001C
7
HUB W/CUPS, 6-BOLTS
815-142C
8
BEARING CUP LM-67010
822-020C
9
BEARING CONE LM-67048
822-021C
10
WASHER SPINDLE - 7/8
804-055C
11
PIN COTTER 5/32 X 1 1/2 LONG
805-089C
12
NUT HEX SLOTTED 7/8-14 PLT
803-029C
13
DUST CAP 2.448X.25X1.13
890-781C
14
WHEEL BOLT 1/2-20X1 1/4 GR5
802-632C
15
AXLE HUB ASSY 12" (Q888)
560-080S
16
WHEEL 15X6 6 BOLT WHITE
814-220C
17
TIRE 9.5 L X 15 8 PLY
814-011C
18
TIRE/WHEEL 9.5LX15 8 PLY WHITE
814-230C
19
CLEVIS PIN 5/16X3W/COTTER PIN
805-324C
20
1"X1/8" COTTER PIN
260216
21
GAUGE WHEEL ARM RH - (SHOWN)
575-533H
GAUGE WHEEL ARM LH
575-534H
22
CASTER GAGE WHEEL TOP COLLAR
575-539H
23
SPRNG COM 1 13/16ODX3/8WX2 3/4
807-226C
24
CASTER GAGE WHEEL SPRING COVER
575-540H
25
WASHER FLAT 1 USS PLT
804-028C
26
NUT HEX 1-8 PLT
803-031C
27
NUT HEX JAM 1-8 PLT
803-030C
28
HUB W/CUPS, 6-BOLTS
815-142C
VERTI-TILL FINISHING ATTACHMENTS
REAR WHEEL ASSEMBLY
Verti-Till Rear Wheel Assembly.xls
