4/21/2004
REF # DESCRIPTION PART NO. COMMENTS
1 45" WHEEL BASKET - RH - (SHOWN) 540-007H VT5300 ONLY
45" WHEEL BASKET - LH 540-043H VT5300 ONLY
60" WHEEL BASKET - RH 540-008H VT5300 & VT7300
60" WHEEL BASKET - LH 540-044H
75" WHEEL BASKET - RH 540-009H VT7300 ONLY
75" WHEEL BASKET - LH 540-045H VT7300 ONLY
2 WHEEL BASKET BRKT (45) - (SHOWN) 540-097H VT5300 ONLY
WHEEL BASKET BRKT (60) 540-098H VT5300 & VT7300
WHEEL BASKET BRKT (75) 540-099H VT7300 ONLY
3 REEL BOLT 45" SC WHEEL BASKET - (SHOWN) 540-055D VT5300 ONLY
REEL BOLT 60" SC WHEEL BASKET 540-054D VT5300 & VT7300
REEL BOLT 75" SC WHEEL BASKET 540-053D VT7300 ONLY
4 BEARING FLG 1 1/2ID 5IN SQ 822-208C
5 RHSNB 1/2-13X1 1/2 GR5 802-106C
6 NUT HEX TOP LOCK 1/2-13 PLT 803-342C
7 RHSNB 1/2-13X2 GR5 802-129C
8 ZERK GUARD ROLLING HARROW 589-085D
9 1/2 LONG X 1/2 BOLT SPACER 585-013D
10 3/4 LONG X 1/2 TINE STOP/SPACR 550-134D
11 HHCS 3/8-16X3 GR5 802-024C
12 NUT LOCK 3/8-16 NYLON INSERT 803-078C
13 NUT HEX SLOTTED 1 1/2-6 PLT 803-301C
14 WASHER MACH 2.25 X 1.50 X 10GA 804-063C
15 PIN COTTER 1/4 X 3 PLT 805-115C
16 REEL HANGER BRACKET 540-014H
17 U-BOLT 5/8-11X3 1/32X4 1/2 SPT 806-183C
18 NUT HEX 5/8-11 PLT 803-021C
19 WASHER LOCK SPRING 5/8 PLT 804-022C
20 1"X5 1/2" WHEEL BRACKET PIN FC0167
21 CLEVIS PIN, 3/8" x 2" PLATED 210632
22 1"X1/8" COTTER PIN 260216
23 SPRING BRACKET-SEEDBED CONDITIONER 540-015H
24 U-BOLT 5/8-11X4 1/32X5 1/2 806-184C
25 GANG SPRING BOLT 540-002H
26 CUPPED WASHER 550-125D
27 10" GANG SPRING - (SHOWN) FC0841 USED ON 45" WHEEL BASKETS
SPRING COMP 2.88OD .531W 9.81L 807-053C USED ON 60" &75" WHEEL BASKETS
28 WASHER FLAT 1 USS PLT 804-028C
29 NUT HEX JAM 1-8 PLT 803-030C
30 PIN CLEVIS 3/4 X 2 1/2 PLT 805-140C
31 WASHER FLAT 3/4 USS PLT 804-024C
32 PIN COTTER 1/8 X 1 1/2 805-225C
VERTI-TILL FINISHING ATTACHMENTS
BASKET ASSEMBLY
Verti-Till Basket Assembly.xls
