Great Plains VT7300 Soil Conditioner Assembly Instructions - Manual (Page 3)

4/21/2004
REF # DESCRIPTION PART NO. COMMENTS
1 CLEVIS PIN, 3/8" x 2" PLATE 210632
2 1"X1/8" COTTER PIN 260216
3 12' CENTERFRAME 540-079H
4 12' TORQUE TUBE SEMI-MOUNT 540-082H
5 12' HITCH FRAME 540-083H
6 MOUNTING BRACKET 540-084H
7 HITCH ARM 540-085H
8 CENTER TURNBUCKLE MOUNT (SHOWN) 540-086H FOR CONDITIONER ONLY
CENTER TURNBUCKLE MOUNT 540-022H FOR RIDGE SPLITTER W/CONDITIONER
9 CONNECTING BAR 540-087H
10 PARKING STAND 540-088H
11 PARKING STAND BRACKET 540-089H
12 CONNECTING BAR BRACKET 540-090H
13 SLIDE TUBE - CONDITIONER ONLY 540-094H ASSEMBLE TO SHORT LENGTH
SLIDE TUBE - SPLITTER & CONDITIONER 540-094H ASSEMBLE TO LONG LENGTH (AS SHOWN)
14 TURNBUCKLE ASSY 24 1/2 540-096S
15 LOCKING BAR 540-133D
16 SPOOL - 1 1/4 OD (SHOWN) 540-153D FOR CONDITIONER ONLY
SPOOL - 1 3/4 OD 540-154D FOR RIDGE SPLITTER W/CONDITIONER
17 HHCS 3/4-10X2 GR5 802-064C
18 HHCS 3/4-10X4 GR5 802-068C
19 HHCS 1-8X5 1/2 GR5 802-205C
20 HHCS 1-8X6 GR5 802-357C
21 HHCS 3/4-10X5 1/2 GR5 802-594C
22 NUT HEX 5/8-11 PLT 803-021C
23 NUT LOCK 3/4-10 PLT 803-026C
24 NUT HEX 3/4-10 PLT 803-027C
25 NUT HEX 1-8 PLT 803-031C
26 NUT HEX 1-8 NYLON INSERT PLT 803-038C
27 WASHER LOCK SPRING 5/8 PLT 804-022C
28 WASHER LOCK SPRING 3/4 PLT 804-023C
29 WASHER FLAT 3/4 USS PLT 804-024C
30 WASHER LOCK SPRING 1 PLT 804-027C
31 PIN HITCH 3/4 X 4 3/8 805-081C
32 PIN CLEVIS 3/4 X 2 1/2 PLT 805-140C
33 PIN HITCH 1 X 4 1/8 USABLE 805-193C
34 PIN COTTER 1/8 X 1 1/2 805-225C
35 U-BOLT 3/4-10X4 1/32X5 3/8 806-012C
36 U-BOLT 5/8-11 X 6 1/32 X 5 3/4 806-016C
37 U-BOLT 5/8-11X4 1/32X5 1/2 806-184C
38 1"X5 1/2" WHEEL BRACKET PIN FC0167
39 PIN AND RETAINER, 3/4 X 3 FC1581
VERTI-TILL FINISHING ATTACHMENTS
FRAME ASSEMBLY
