Carefully slide the inner glass towards you and withdraw it from its
locating slots.
Ensure that the door is not allowed to slam shut, due to the
reduction in door weight.
Clean the glass as described above.
Refit the door inner glass as follows.
1. Open the door fully.
2. Locate the inner door glass into its slots, so that the printing is readable from the face
nearest the oven in the closed position and the widest black band is towards the bottom of
the door. The inner door glass has a special reflective coating on one side, in order to
minimise surface temperatures and energy consumption during use, it is important it is
fitted correctly.
3. Carefully slide the glass into its slots as far as it will go and replace the end caps.
2.
3. The inside of the outer door glass can now be cleaned while still fitted to the cooker.
NEVER OPERATE THE COOKER WITHOUT THE INNER DOOR GLASS IN POSITION.
CLEANING THE DOORS
Take particular care not to damage the inner surface of the door inner glass that is coated
with a heat reflective layer. Do not use scouring pads, or abrasive powder, which will
scratch the glass.
Ensure that the glass panel is not subjected to any sharp mechanical blows.
Stubborn stains can be removed by using a fine steel wool soap pad. For slight soiling the inner
glass panel may be cleaned, while still warm, without removing it from the door. After cleaning,
rinse and dry with a soft cloth.
SIDE OPENING DOOR
Cleaning the door glass is the same as the drop down door, except take care to support the
weight of the inner glass when removing and refitting.
DROP DOWN DOORS
Remove the door inner glass as follows.
1. Open the door fully and remove the extrusion end caps (This should be done by hand but if
it proves too difficult, simply lift the inner glass to ease the end caps out of position).
Note: If you need to use a tool - be careful not to damage the extrusion or end cap.
