Assemble the right & left hand tool bar brace (#1), Hitch with the 3/4" x 2" long bolts (#2), Washers (#3), and the 3/4" hex nuts (#4) – Great Plains 20’ CPH Operator Manual User Manual

Page 7: 5) is designed to be turned two different di, Support weldment (#5), Fasten the tool bar support weldments (#5) to the, 6), 5/8" lock washer (#7), 8). do not tighten bolts yet

background image

-

5

3/31/04

Great Plains Mfg., Inc.

1994 20’ CPH Coulter Tool Bar Brace Assembly 149-721M

Ref.

Part No.

Part Description

Section 4 Coulter Tool Bar Brace Assembly

1.

149-166H

20’ CPH Tool Bar Brace - Left Hand

149-167H

20’ CPH Tool Bar Brace - Right Hand

2.

802-064C

Screw, Cap Hex Head 3/4"-10 x 2" Long

3.

804-023C

Washer, Lock Spring 3/4"

4.

803-027C

Nut, Hex 3/4"-10

5.

149-165H

20’ Tool Bar Support

6.

806-063C

U-Bolt 5/8"-11 x 4 1/32" x 7" Long

7.

804-022C

Washer, Lock Spring 5/8"

8.

803-021C

Nut, Hex 5/8"-11

9.

804-030C

Washer, Lock Spring 1 1/4"

10.

802-123C

Screw, Cap Hex Head 1 1/4"-7 x 2 1/2" Long

11.

149-586D

CPH Brace Kit Spacer
