Using this Manual
1994 20’ CPH Coulter Tool Bar Brace Assembly 149-721M
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Using This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Section 1 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Section 2 Assembly Instructions & Set-Up . . . . . . 2
Torque Values Chart. . . . . . . . . . . . . . . . . . . . . . . 2
Pre-Assembly Checklist . . . . . . . . . . . . . . . . . . . . 3
Assembling The Coulter Tool Bar Brace
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Post-Assembly Checklist . . . . . . . . . . . . . . . . . . . 3
Section 3 Basic Operation . . . . . . . . . . . . . . . . . . . 3
Section 4 Parts Book . . . . . . . . . . . . . . . . . . . . . . . . 4
Coulter Tool Bar Brace Assembly . . . . . . . . . . . . 4
Table of Contents
This manual has been prepared to instruct you in the
safe and efficient operation of your
Coulter Tool Bar Brace Assembly.
Read and follow all
instructions and safety precautions carefully.
The parts on your
1994 20’ CPH Coulter Tool Bar Brace
have been specially designed and should
only be replaced with genuine
Great Plains
parts. There-
fore; should your
Coulter Tool Bar Brace Assembly
require replacement parts, go to your
Great Plains
Dealer.
The right hand and left hand as used throughout this
manual is determined by facing in the direction the ma-
chine will travel when in use unless otherwise stated.
Product Overview
The Great Plains Coulter Tool Bar Brace Assembly is
designed to enhance the performance of your Center
Pivot Hitch in extremely hard soil conditions by reducing
the upward flex on the ends of the 20’ coulter tool bars
,thus giving better coulter depth control.
This assembly is not needed and will not fit on a CPH
with the coulter tool bar weight brackets assembled on
the end of the coulter tool bars.
The SAFETY ALERT SYMBOL indicates that there is a
potential hazard to personal safety involved and extra
safety precautions must be taken. When you see this
symbol, be alert and carefully read the message that fol-
lows it. In addition to design and configuration of
equipment; hazard control and accident prevention are
dependent upon the awareness, concern, prudence and
proper training of personnel involved in the operation,
transport, maintenance and storage of equipment.
Watch for the following safety notations throughout
your Operators Manual and on your Center Pivot
Hitch:
!
DANGER!
Indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury. This signal
word is limited to the most extreme situations.
!
WARNING!
Indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
!
CAUTION!
Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury. It may also
be used to alert against unsafe practices.
NOTE: Indicates a special point of information which
requires your attention.
Introduction
!
are the Operator’s and the Parts Manual.
For your safety and to help in developing a better under-
standing of your equipment we highly recommend that
you read the operator sections of this manual. Reading
these sections not only provides valuable training but
also familiarizes you with helpful information and its lo-
cation. The parts sections are for reference only and
don’t require cover to cover reading. After reviewing the
manuals store them in a dry, easily accessible location
for your future reference.
