4 1300 Seed-Box Agitator 175-208M 3/8/07
Great Plains Mfg., Inc.
Assembly
■
Agitator Paddle Installation
Slip one paddle (1) over the agitator shaft directly above a seed
cup. Slip a 1/4-by-2-inch flange bolt (2) through the paddle and
secure with a flange lock nut (3). Before tightening bolt, carefully
rotate the drive system to make sure paddle does not hit the tray
dividers.
After checking for interference, torque bolts to 9 foot pounds (108
inch pounds).
Install the next paddle over the next seed cup. Index paddle 1/6th
of a turn by sliding it onto the next set of shaft flats. Continue the
installation using the next set of flats for each paddle.
17046
