9. A PPENDIX W HEATHEART - P OST P OUNDER
9.3. S PECIFICATIONS & D RIVE O PTIONS H IGH & H EAVY H ITTER AND H IGH & H EAVY H ITTER P LUS
42 IM4 R3
9.3. SPECIFICATIONS & DRIVE OPTIONS
The post hugger is standard equipment on all post pounders, for added safety
and convenience.
The High and Heavy Hitter Plus has the same features as the standard High and
Heavy Hitter models, but includes a 720 lb heavy duty hammer, additional weight
to ballast box for greater stability, PTO pump drive or 13 hp honda motor on
trailer mount, and hammer height adjustable from 9' 8" to 14' 5" in raised
position. Skid Steer/3PT Center Mast models include inline hydraulic oil filter on
return line (self contained units only).
* 2-Position adjustable mast on Heavy Hitter & Heavy Hitter Plus
**4 Position adjustable bolt on cast head on Heavy Hitter & Skid steer pounder, 3 Position adjusta-
ble bolt on cast head on Heavy Hitter Plus
*** Requires return line plumbed directly into skid steer / tractor hydraulic oil resevoir.
† Self contained hydraulics has on-board oil resevoir with pump and hydraulic motor driven by skid
steer hydraulics.
††Self contained hydraulics has on-board oil resevoir with PTO pump driven by tractor PTO.
MODEL H&H TRAILER
H&H 3-PT HITCH SIDE
MAST
H&H PLUS
TRAILER
TOTAL WT. (W/HUGGER) 2580 lb (1170 kg) 2220 lb (1007 kg) 2930 lb (1329 kg)
HAMMER WEIGHT 660 lb (299 kg) 660 lb (299 kg) 720 lb (326 kg)
TRANS. HT. (2 - POSITION*) 8' 2", 8' 10" (249, 269 cm) - 8' 9", 9' 5" (267, 287 cm)
SHIPPING HT. (2 - POS.*) - 8' 2", 8' 10" (249, 269 cm) -
WIDTH (TRANSPORT) 7' 2" (218 cm) 6' 2" (188 cm) 7' 2" (218 cm)
LENGTH 10' 1" (307 cm) 5' 4" (163 cm) 10' 6" (320 cm)
HAMMER HT. MAX (ADJ.**) 9' 6"-11' 11" (290-363 cm) 9' 6"-11' 11" (290-363 cm) 9' 8" - 14' 5" (295-439 cm)
HAMMER HEIGHT MIN
4' 2" (127cm) 4' 2" (127cm) 4' 2" (127cm)
STROKE 64" (163cm) 64" (163 cm) 66" (168 cm)
DRIVE
PTO PUMP DRIVE
GAS (9 HP HONDA)
PTO PUMP DRIVE
PTO PUMP DRIVE
OR GAS (13 HP HONDA)
HYD. REQ. (MINIMUM) - - -
TILT ADJ. - FRONT/BACK 50° (25° FROM VERT.) 50° (25° FROM VERT.) 50° (25° FROM VERT.)
TILT ADJ. - LEFT/RIGHT 30° (15° FROM VERT.) 30° (15° FROM VERT.) 30° (15° FROM VERT.)
TIRES 15'' - 15"
MODEL
H&H PLUS
3-PT HITCH SIDE MAST
H&H SKID STEER
H&H 3-PT HITCH
CENTER MAST
TOTAL WT. (W/HUGGER) 2450 lb (1111 kg) 1500 lb (680 kg) 1410 lb (640 kg)
HAMMER WEIGHT 720 lb (326 kg) 660 lb (299 kg) 660 lb (299 kg)
TRANS. HT. (2 - POSITION*) - - -
SHIPPING HT. (2 - POS.*) 8' 9", 9' 5" (267, 287 cm) 8'2" (249 cm) 8'2" (249 cm)
WIDTH (TRANSPORT) 6' 2" (188 cm) 36" (91 cm) 36" (91 cm)
LENGTH 5' 4" (163 cm) 43" (109 cm) 43" (109 cm)
HAMMER HT MAX (ADJ.**) 9' 8" - 14' 5" (295-439 cm) 9' 6"-11' 3" (290-363 cm) 9' 6"-11' 3" (290-363 cm)
HAMMER HEIGHT MIN 4' 2" (127 cm) 4' 2" (127 cm) 4' 2" (127 cm)
STROKE 66" (168 cm) 64" (163 cm) 64" (163 cm)
DRIVE PTO PUMP DRIVE
***SKID STEER HYD.
†SELF CONTAINED HYD.
***TRACTOR HYD.
††SELF CONTAINED
HYD.
HYD. REQ. (MINIMUM) -
10 gpm @ 1500 psi

(38 L/m @103 bar)
10 gpm @ 1500 (38 L/m
@103 bar)
TILT ADJ. - FRONT/BACK 30° (15° FROM VERT.) 26° (13° FROM VERT.) 26° (13° FROM VERT.)
TILT ADJ. - LEFT/RIGHT 50° (25° FROM VERT.) 40° (20° FROM VERT.) 40° (20° FROM VERT.)
