Page 3

TABLE OF CONTENTS
TABLE OF CONTENTS
1.0 OVERVIEW ............................................................................. 1
1.1 Display Panel / Definition of Buttons ........................... 2
2.0 PREPARATION FOR USE ........................................................ 4
2.1 Power ............................................................................ 4
2.2 Input / Output Connections .......................................... 4
3.0 MENU ...................................................................................... 6
4.0 OPERATION ............................................................................ 7
4.1 Internal Mode - Standard Strobe Operation ............... 8
4.2 Internal Mode - TACH Frequency Generator ............. 10
4.3 External Input Mode ................................................... 11
10. This instrument is not user serviceable. For technical
assistance, contact the sales organization from which you
purchased the product.
In order to comply with EU Directive 2002/96/EC on Waste
Electrical and Electronic Equipment (WEEE): This product
may contain material which could be hazardous to human health
and the environment. DO NOT DISPOSE of this product as un-
sorted municipal waste. This product needs to be RECYCLED in
accordance with local regulations, contact your local authorities
for more information. This product may be returnable to your distributor for
recycling - contact the distributor for details.
Monarch Instrument’s Limited Warranty applies. See
www.monarchinstrument.com for details.
Warranty Registration and Extended Warranty coverage available
online at www.monarchinstrument.com.
10.0 OPTIONS AND ACCESSORIES
C-4027
Set of mating 1/8 inch (3.5mm) stereo phone plugs (to
provide TTL signal and sensor power)
CA-4044-6
6 foot (1.8M) input / output cable, 1/8 inch (3.5mm)
male phone plug to male BNC connector
CA-4045-6
6 foot (1.8M) input / output cable, 1/8 inch (3.5mm)
male phone plug to 1/8 inch (3.5mm) male phone plug
for daisy chaining strobes together
CA-4046-6
6 foot (1.8M) Accelerometer input cable, 1/8 inch
(3.5mm) male phone plug to BNC with BNC union
connector
CC-7
Latching carrying case for Strobe with provision for
accessories
L-1903
Digital Stroboscope replacement lamp
SPC-1
Splash proof Protective Cover for battery model
Stroboscopes ONLY
ROS-P
Remote Optical Sensor with 8 foot (2.5 m) cable for
triggering strobe
T-5
Reflective tape. 5 foot (1.5 m) roll, 0.5 inch wide
MT-190P
Magnetic Sensor/Amplifier with 8 foot (2.5 m) cable
for triggering strobe
IRS-P
Infrared Sensor for use without reflective target at 0.5
inch (12 mm) gap with 8 foot (2.5 m) cable for triggering
strobe
Accelerometer
100 mV/g with 6 foot coiled cable, ¼” x 28 Tapped Hole
30
