Monarch Instrument MVS Frequency Controller User Manual

Page 2

Monarch Instrument

15 Columbia Drive

Amherst, NH 03031 USA

Phone: (603) 883-3390

Fax: (603) 886-3300

E-mail: [email protected]

Website: www.monarchinstrument.com

1071-4280-290R

0611

The strobe has a Menu which allows the user to select settings such as number of decimal places, backlight on or off and positive or negative edge for input and
output signal.

To enter the MENU:
1.

Press the

ALT FUNCTION button and then the MENU button.

SETUP

and the menu option will be displayed.

Turn the tuning knob to cycle through the main menu options.

Once the desired menu option is displayed, press the MENU button to select it. Press any other button to cancel.

Turn the tuning knob to edit the menu option setting.

Press the MENU button to save your changes. Press any other button to cancel.

Press any button other than MENU to exit the Main Menu.

DONE

will be displayed.

Below is a list of the menu items:

DECPT

- Decimal Point (none, 1 or 2)

BLITE

- Backlight (Yes=On or No=Off)

INPUT

- Positive (pos) or Negative (neg) Edge for Input Signal

OUTPT

- Positive (pos) or Negative (neg) Edge for Output Signal

In order to comply with EU Directive 2002/96/EC on Waste Electrical and Electronic Equipment (WEEE):
This product may contain material which could be hazardous to human health and the environment. DO NOT DISPOSE of this product as unsorted
municipal waste. This product needs to be RECYCLED in accordance with local regulations, contact your local authorities for more information.
This product may be returnable to your distributor for recycling - contact the distributor for details.

Monarch Instrument’s Limited Warranty applies. See

www.monarchinstrument.com

for details.

Warranty Registration and Extended Warranty coverage available online at
