Monarch Instrument PT99 - Manual (Page 6)

E-3
4.0 PT99 SPECIFICATIONS
Speed Range: 5 to 99,999 RPM
Accuracy: ± 0.01% of reading or ± 1 digit
Resolution: 0.001 RPM to 1 RPM
Operating Range: 36” (91.44 cm) up to 30 degrees off perpendicular
Display: 5 Digits, 5 Alpha-numeric LCD
Light Source: Red LED
Batteries: 2 “AA” 1.5 V (DC) alkaline included
(Note: Batteries are NOT rechargable)
Battery Life: 60 hours continuous typical with provided batteries
Dimensions: 6.92” (17.58 cm) H x 2.4” (6.10 cm) W x 1.6” (4.06 cm)
D
Weight: approx. 7 oz. (210 g)
This product is designed to be safe for indoor use under the following
conditions (per IEC61010-1).
Installation Category II per IEC 664
Pollution Degree Level II per IEC 664
Temperature: 40 °F to 105 °F (5 °C to 40 °C)
Humidity: Maximum relative humidity of 80% for temperatures up
to 88 °F (31 °C) decreasing linearly to 50% relative
humidity at 100 °F (40 °C). Humidity non-condensing.
Specifications subject to change without notice.
S-4
5.0 MEDIDAS SIN CONTACTO
5.1 Preparación para la Medida
1. Limpie
la barra
Tan pequeñas coms
1/8” de ancho en el
lado o borde radio
2. Aplique 1/2
pulgada de
cinta reflectiva
cuadrada T-5
Para barras pequeñas:
