15
SHR Series Woodburning Fireplaces
20001384
FP1166
surround flush
with finished wall
12/20/01 djt
Stud
2 x 4 Header
Ledge Bracket
Surround
Must be Sealed with
Noncombustible
Material
Noncombus-
tible Decorative
Facing
Finished Wall
FP1166
Fig. 26 Fireplace surround flush with finished wall.
FP1277
SHR52
drywall finish
1/30/03 djt
Finished Wall
Framing Shield
FP1277
Fig. 25 SHR52 framing shield may be used to attach finish
material.
Must be
sealed with
noncombustible
material
�����
�������������������
�����������
��������������
12"
(305mm)
Max.
12"
(305mm)
min.
*
1���"
12"
(305mm)
Max.
12"
(305mm)
min.
1���"
6"
(159mm)
Min.
1"
FP531
Fig. 24 Mantel clearance.
Header
Must be sealed with non-
combustible material
Surround
Face
Finished Wall
Ledge Bracket
Finished Wall
Ledge Bracket
Combustible Mantel
and Trim
Mantel Clearance -
No Noncombustible Facing Material
Fireplace Opening * Minimum width from
top of surround to bottom
of screen rail
Noncombustible
Material
Combustible
Mantel and Trim
Mantel Clearance -
with Noncombustibel Facing Material
Finished Wall
Header
Ledge Bracket
Noncombustible
Material
Surround
Face
Noncombustible Facing
Material
Fireplace Opening
2 x 4 Stud
Finished Wall
Must be sealed with
noncombustible
material
