Specifications
LHER20
LHERDV20
LHEC20
LHECDV20
LHEC30
LHECDV30
LHER30
LHERDV30
BTU Input High
20,000 LP & NG 20,000 LP & NG 20,000 LP & NG
20,000 LP & NG
30,000 LP & NG
30,000 LP & NG 30,000 LP & NG 30,000 LP & NG
BTU Input Low
15,000 LP/
15,000 LP/
15,000 LP/
15,000 LP/
22,500 LP/
22,500 LP/
22,500 LP/
22,500 LP/
14,000 NG
14,000 NG
14,000 NG
14,000 NG
21,000 NG
21,000 NG
21,000 NG
21,000 NG
EnerGuide Ratings
51%
59.7%
51.2%
61.3%
48.5%
61.5%
48.3%
59.9%
Fireplace Efficiency
Steady State Efficiency
70% LP/
70% LP/
76% LP/
73% LP/
73% LP/
74% LP/
73% LP/
74% LP/
(with fan on)
69% NG*
69% NG*
75% NG
72% NG
72% NG
73% NG
72% NG*
73% NG*
AFUE by DOE Ratings
59%
64%
60%
65%
64%
66%
67%
71%
LHEC30 model shown with Georgian
Traditional Cast Surround & cast bay
window in Ebony Black and brick
lining • 30DVSGTKB, 30DVBGTKB,
LHEC30CR
Vermont Castings is renowned for its beautiful fine
carvings in cast iron. The smooth finish accentuates
the cast surround and cast bay window.
I t ’s a l l i n t h e d e t a i l s
*Fan n/a for this model
40 15/16”
26 3/4”
41 1/2”
3
26 9/16”
38 9/16”
39 5/8”
28
5/
16
”
28
13
/1
6”
47 5/8”
30 3/8”
29 1/8”
42 5/16”
5 13/16”
21 3/8”
2 3/8”
G
5”
3 0 ” M a r q u e t t e F a c e Tr i m K i t
3 0 ” R o m a n e s q u e F a c e Tr i m K i t
3 0 ” G e o r g i a n C a s t S u r r o u n d a n d B a y
LHEC30
model
shown
with
Romanesque
in
Modern
Pewter
• 30DVSRFKS
LHEC30 model shown with Marquette
in Rustic Bronze • 30DVSMTKR
