Vermont Casting Insert Studio LHEC30 - Manual (Page 3)

LHEC20 model shown with Adjustable
Bevel Steel Surround in Black with
cast keystone & boots, black arched
door, base riser and brick lining •
LHEABSL, LHEC20DKB, LHEC20FB,
LHEC20CR LHEC20 model with Large Surround in
Black, Black filigree louvers and brick
lining
• LHE20SLB, LHEC20LKB,
LHEC20CR
LOUVER KIT OPTIONS LHEC30 LHER30 LHEC20 LHER20
Std. Louver Top & Bottom Black √ √
Filigree Top & Bottom Black √ √
Filigree Top & Bottom Pewter √ √
Filigree Top & Bottom Gold √
HEBTK Window Adapter kit √
FACE KITS/SURROUNDS
Romanesque
Ebony Black √
Rustic Bronze √
Modern Pewter √
Marquette
Ebony Black √
Rustic Bronze √
Modern Pewter √
Georgian Square Surround
Classic Black √
Ebony Black √
Georgian Bay Surround
Classic Black √
Ebony Black √
L H E I N S E R T O P T I O N S
SURROUND OPTIONS LHEC30 LHER30 LHEC20 LHER20
Small Surround – Black 4.5" √ √ √ √
Large Surround – Black 6" √ √ √ √
Large Surround Antique – Brass 6" √ √
Mead Surround Large – Black √ √ √ √
Mead Surround Large – Ebony Black
enamel
√ √
Caprice Surround Classic – Black √ √ √ √
Caprice Surround Ebony – Black √ √ √ √
Adjustable Bevel Steel Surround Large √ √ √ √
BAY FACE KIT (must purchase surround separately)
Traditional Cast Bay – Classic Black √ √
Steel Bay Window w/ Filigree – Black √ √
SURROUND KIT BASE RISERS
1" Trim Base riser – Black √ √ √ √
2" Trim Base riser – Black √ √ √ √
2" Trim Base riser – Black √ √ √ √
ACCESSORIES
Trim Closure Kit – Black for XL Fireplace √ √ √ √
Arch Door Kit, Black √ √
Ceramic Fiber Brick Firebox Liner √ √ √ √
Zero Clearence Kit √ √ √ √
Outside Air Kit (for use with HEZC) √ √ √ √
IMT Thermostat w/ Face Plate √ √ √ √
1. Choose an insert by size, BTUs and venting
system (your Vermont Castings dealer will be
able to help you here).
2. Choose face kit(s) – goes on the front of the
insert, choices vary by model.
3. Choose a surround – goes around the insert
and closes off the fireplace opening. Again,
choices vary by model.
4. Choose additional accessory – brick lining,
remote control, thermostat.
H O W T O B U I L D Y O U R C U S T O M I N S E R T :
LHEC20 model shown with Mead
Traditional Cast Surround & cast bay
window in Classic Black, base riser
and
brick lining • LHEC20CBTK,
LHE20CSLB, LHER20R1, LHEC20CR
