Vermont Casting Insert Studio LHEC30 User Manual
Page 5
Models: LHER20, LHEC20,
LHER30, LHEC30
Models: LHERDV20, LHECDV20,
LHERDV30, LHECDV30
LHEC30 model shown with Large
Surround in Black, regular flat louvers
and
brick
lining
•
LHEC30SLB,
LHEC30FB, LHEC30CR
IDEAL FOR HOMES WITH
NEGATIVE PRESSURE
PROBLEMS
LHEC30 model shown with Adjustable
Bevel Steel Surround in Black with
cast keystone & boots, steel bay
window, Black bay trim • LHEABSL,
LHEC30BTK, LHEC30BLKS
LHEC30
model
shown
with
Large
Surround in Antique Brass with gold
plated
edge,
Black
arched
doors,
regular flat louvers and brick lining •
LHE30SLGA, LHEC30DKB, LHEC30FB,
LHEC30CR
How Vermont Castings
Natural Vent Gas Inserts Work:
How Vermont Castings
Direct Vent Gas Inserts Work:
ARROW LEGEND
COLD AIR FOR COMBUSTION
EXHAUST
RADIANT HEAT
CONVECTED HEAT
