VRX6671z
43
1.
BEFORE STARTING..................................................43
2.
PACKAGE CONTENTS...............................................43
3.
GENERAL CAUTIONS................................................44
4.
CAUTIONS ON INSTALLATION.................................44
5.
INSTALLING THE MAIN UNIT....................................45
6.
REMOVING THE MAIN UNIT.........................................47
7.
CAUTIONS ON WIRING................................................48
8.
WIRE CONNECTION ................................................49
9.
SAMPLE SYSTEMS...................................................51
■
Contents
VRX6671z
1. This set is exclusively for use in cars with a
negative ground 12 V power supply.
2. Read these instructions carefully.
3. Be sure to disconnect the battery “
” termi-
nal before starting. This is to prevent short
circuits during installation. (Figure 1)
1
1
1
1
1
Main unit
2
2
2
2
2
Manuals
Owner’s manual & Installation manual
Warranty card
3
3
3
3
3
Power supply lead
4
4
4
4
4
Bag for accessories of the main unit (No. 1)
Flat head screw (M5
×
8)............................4
Sems hexagonal bolt (M5
×
8)....................5
5
5
5
5
5
Bag for accessories of the main unit (No. 2)
Hook plate..................................................2
Cord clamp
Spacer
Special screw
6
6
6
6
6
Universal mounting bracket
7
7
7
7
7
Remote control unit
8
8
8
8
8
Battery
(for remote control unit)
9
9
9
9
9
Outer Escutcheon
0
0
0
0
0
DCP Case
1.
BEFORE STARTING
2.
PACKAGE CONTENTS
Installation and Wire connection manual
