Quoizel CHI8413IB Chimera - Manual

Warnings and Cautions
Turn off electricity at circuit breaker or main fuse box before installation. Consult a licensed electrician if in doubt.
These instructions are provided for your safety. It is very important you read them completely before installing
the fixture. We strongly recommend that a licensed, professional electrician perform the installation.
Disconnect fixture from power source before replacing bulbs. Make sure bulbs are given sufficient time to cool
before removal. Do not subject glass parts to any shock while in operation or shattering may result.
Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
2013 QuoizelInc.
1of8
Assembly Instruction Sheet #IS-CHI8413IB
For Style CHI8413IB
Part Description Quantity
A Inner Backplate
Wall Anchor
1 pc.
2 pcs.
2 pcs.
2 pcs.
4 pcs.
4 pcs.
4 pcs.
2 pcs.
B
C
D
E
Mounting Screw (1.5”L)
Mounting Screw 1.25”L) (
Package Contents
Lock Washer
Self-tapping Screw
A
B
C
D E
Tools Required: Flathead screwdriver, Phillips screwdriver, pliers, wire cutters, wire
strippers, electrical tape, safety glasses.
Estimated Assembly Time: 20-30 minutes
Bulb Recommended: (4) Candelabra Base Bulbs 60W Maximum
Preparation: Identify and inspect all parts before beginning installation. Check package
content list and diagrams below to be sure all parts are present. If any parts are missing
or damaged, do not attempt to assemble, install, or operate the fixture. Contact customer
service for replacement parts.
March2013
Quoizel, Inc.
6 Corporate Parkway
Goose Creek, SC
29445
Customer Service
Phone 631.273.2700
Fax
631.231.7102
www.quoizel.com
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
, .
. .
F
F
Hex Nut
Mounting Ball
G
H
G
Fixture Body
H
I
1 pc. I
J
Cage with Shade 1 pc. J
