Quoizel CAN8409WB Carson User Manual

Package contents, Warnings and cautions

Part

Description

Quantity

Crossbar

1 pc.

2 pcs.

Finial

Hex Nut

Lock Washer

Package Contents

6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com

Quoizel, Inc.
6 Corporate Parkway
Goose Creek, SC
29445

Customer Service
Phone 631.273.2700
Fax

631.231.7102

www.quoizel.com

Warnings and Cautions

Turn off electricity at circuit breaker or main fuse box before installation. Consult a licensed electrician if in doubt.

These instructions are provided for your safety. It is very important you read them completely before installing
the fixture. We strongly recommend that a licensed, professional electrician perform the installation.

Disconnect fixture from power source before replacing bulbs. Make sure bulbs are given sufficient time to cool
before removal. Do not subject glass parts to any shock while in operation or shattering may result.

Thank you for purchasing a Quoizel product.

Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700

or visit us on-line at www.quoizel.com

2011 QuoizelInc.

Mounting Ball

Mounting Screw

Assembly Instruction Sheet #IS-CAN8409WB

For Style CAN8409WB

1of5

Tools Required: Flathead screwdriver, Phillips screwdriver, pliers, wire cutters, wire
strippers, electrical tape, safety glasses.

Estimated Assembly Time: 20-30 minutes

Bulb Recommended: (1) Medium Base 100W Maximum

Preparation: Identify and inspect all parts before beginning installation. Check package
content list and diagrams below to be sure all parts are present. If any parts are missing
or damaged, do not attempt to assemble, install, or operate the fixture. Contact customer
service for replacement parts.

1 pc.

Cover

Waterproof Washer

Cup

Nipple with Hex Nut

September2011

1 pc.

Fixture Body
