Quoizel PIE8701PN Pier - Manual (Page 5)

Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
2013 QuoizelInc.
5of5
Assembly Instruction Sheet #IS-PIE8701PN
For Style PIE8701PN
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
, .
. .
July2013
STEP 6 Attach Shade to Fixture
-
A. Place Small Shade (I) into Upper Shade Holder on the
Fixture Body (G) properly. Big Shade (H) into Lower Shade
Holder on the Fixture Body (G) properly.
Your fixture is now assembled and ready to use.
Enjoy!
Lower Shade
Holder
Figure 7
Big Shade
Small Shade
Figure 6
Bulb
Socket
STEP 5
- Install Bulb
A. This fixture uses standard bulbs with a standard screw base.
Maximum 60 watts.
B. Insert bulb and screw properly into place.
Upper Shade
Holder
