Quoizel LSM8801GY Millennium - Manual

PACKAGE CONTENTS
INSTRUCTION SHEET IS LSM8801
-
STYLE NUMBER:
LSM8801TM ,LSM8801PS,LSM8801GY
ISSUED 10-2008
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
, .
. .
Part
A
E
C
G
H
B
F
D
Description
Lock Washer
Hex Nut
Backplate
Shade
Crossbar
Green Ground Screw
Mounting Screw
Mounting Ball
Quantity
1pc
2pcs
2pcs
1pc
2pcs
2pcs
1pc
1pc
A
B
C
D
E
F
G
H
WARNINGS AND CAUTIONS
!
PREPARATION
INSTALLATION INSTRUCTIONS
WARNING:
● Before beginning the installation, turn off electricity at the circuit breaker box or the main fuse box by
switching off the circuit breaker or removing the fuse.
CAUTIONS:
● These instructions are provided for your safety. It is very important that they are read completely before
the installation of your fixture. We strongly recommend that a professional electrician install the fixture.
● Disconnect fixture from the power source before replacing the bulb(s), making sure the bulb(s) had
sufficient time to cool down. DO NOT subject the lamp to any shock while lit as shattering of lamp may
result.
● Before beginning installation of product, make sure all parts are present. Compare parts with package
contents list and diagram above. If any part is missing or damaged, do not attempt to assemble, install or
operate the product. Contact customer service for replacement part.
● Estimated Assembly Time: 10 20 minutes
● Tools Required for Assembly (not included): Flathead screwdriver Phillips screwdriver, pliers, electrical
tape, wire cutters, safety glasses &1, 60 Watts, B10 Candelabra Base Bulb.
● Helpful Tools (not included): Wire Strippers.
-
,
1 OF 2
Outlet Box
Crossbar
Mounting Screw
Hex Nut
Outlet Box Screw
Lock Washer
STEP 1:
a Screw the Mounting Screws into the Crossbar place the
Lock Washers over the Mounting Screws and thread the
Hex Nuts onto the Mounting Screws as shown
Secure the
position of the Mounting Screws by tightening the Hex Nuts
against the Crossbar
b Secure the Crossbar to the Outlet Box with Outlet Box
Screws
. ,
.
.
.
.
