Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
3of4
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
, .
. .
2013 QuoizelInc.
Assembly Instruction Sheet #IS-TF1697FWT
For Style TF1697FWT
September2013
Part Description Quantity
A 1 pc.
1 pc. B Shade
Package Contents
A
B
1 pc. C
Finial
D
H
1 pc.
D
E
C
Socket Assembly
Stem 6”L
Rod F
G 1 pc.
F
1 pc.
Rod with Connecter
1 pc.
E
H 1 pc.
Flat Washer
G
Base
Figure 1
STEP 1 Assemble Rod and Socket
Assembly
-
A. Thread the Socket Assembly (E), the Rod (F) and Rod
with Connecter (G) to the Base (H) as shown. Hand
tighten until snug.
Rod
Base
Socket
Assembly
Rod with
Connecter
