Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
3of4
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
, .
. .
Figure 1
STEP 2
- Assemble Harp
A. Locate the Harp (A) by pressing the bottom ends of the
Harp (A) into the Harp Clips.
Figure 2
2012 QuoizelInc.
Harp Clip
Harp
STEP 1 Assemble Rod and Socket
Assembly
-
A. Thread the Rod (E) and Panel (F) to the Base (G) as
shown. Hand tighten until snug.
B. Thread the Socket Assembly (B) into the top end of Rod
(E). Hand tighten until snug.
Rod
Rod
Panel Socket Assembly
Assembly Instruction Sheet #IS-Q1055FBN
For Style Q1055FBN
November2012
