Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
2013 QuoizelInc.
Assembly Instruction Sheet #IS-TF1694TVK
For Style TF1694TVK
August2013
Part Description Quantity
A 1 pc.
1 pc.
1 pc.
1 pc.
B
C
D
Socket Assembly
Base
Stem 5”L
Package Contents
A
B
C
D
Finial
1 pc. E
E
Flat Washer
STEP 1 Install Socket Assembly
-
A. Thread the Socket Assembly (B) onto the nipple on the
top center of the Base (C). Hand tighten until snug.
Figure 1
F
1 pc. F Shade
Shade
Socket
Assembly
