Assembly Instruction Sheet #IS-TF1510TVB
For Style TF1510TVB
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
, .
. .
STEP 3 attach Shade to Fixture Body -
A. Thread Big Knurled Nut (C) onto Center Stem (G).Hand
tighten until snug.
B. Place Shade (B) over Center Stem (G).Adjust the Big
Knurled Nut (C) to proper location for the Shade (B) and
Finial (A). secure by thread Finial (A) onto the Center
Stem (G), hand tighten until snug.
Figure 3
Shade
Big Knurled Nut
2013 QuoizelInc.
Center Stem
Finial
STEP 4 - Install Bulb
A. This fixture uses standard bulb with standard screw
base . Maximum 75 watts.
B. Insert bulb and screw snugly into place.
Your lamp is now assembled and ready to use.
Enjoy!
Figure 4
Bulb
Socket
