Figure 1
Assembly Instruction Sheet #IS-TF1504TWT
For Style TF1504TWT
STEP 1 Install the Stem
-
A. Screw the beaded end of the Stem with Knurled Nut (A)
into the Coupling on the top center of the Base (B).
Hand tighten until snug.
Base
Harp
Coupling
June2012
STEP 2
- Attach Shade
A. Adjust the Knurled Nut on the top end of the Stem (A) to
proper location for the Shade (D) and the Finial (C).
B. Place the Shade (D) onto the top end of the Stem (A).
Secure by threading the Finial (C) onto the Stem (A).
Hand tighten until snug.
Finial
Figure 2
Stem
Shade
STEP 3 Install Bulb
-
A. This fixture uses standard bulb with medium base .
Maximum 75 watts.
B. Insert bulb and screw snugly into place.
Figure 3
Bulb
Socket
Knurled Nut
