Assembly Instruction Sheet #IS-Q1702TBN
For Style Q1702TBN
July2014
STEP 1 Install Socket Assembly
-
A. Thread the Socket Assembly (B) onto the nipple on the
top center of the Base (C). Hand tighten until snug.
Figure 1
Socket Assembly
Base
STEP 2 Install Harp
-
A. Install the Harp (A) onto the Socket Assembly (B) by
pressing the ends of the Harp (A) into the Harp Clips.
Figure 2
Socket Assembly
Harp
STEP 3 Install Shade
-
A. Place the Shade (E) onto the top end of the Harp (A) and
secure with the Finial (D). Hand tighten until snug.
Figure 3
Shade
Harp
Finial
Harp Clip
