Quoizel WIN1718C Wain - Manual (Page 5)

Assembly Instruction Sheet #IS-WIN1718C
For Style WIN1718C
Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
5of5
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
, .
. .
2012 QuoizelInc.
STEP 5
- Attach Shade to Socket Assembly
A. Place Shade (J) over the Socket and secure with
Socket Collar (I). Hand tighten until snug.
Figure 6
Socket
Collar
Shade
Socket
Figure 7
Bulb Shield
G9 Bulb
Socket
STEP 6 Install Bulb and Bulb Shield
-
A. This fixture uses Frosted G9 Halogen Bulbs. Maximum 75
watts (supplied).
B. Insert bulb and seat properly into place.
C. Screw Bulb Shield (G) onto the Socket and hand tighten
until snug.
Your fixture is now assembled and ready to use.
Enjoy!
CAUTION FOR BULB REPLACING
A. When replace bulb, turn off power and allow lamp to cool. For safety purpose, wear gloves and eye protection.
B. If bulb is scratched or cracked, DO NOT use the lamp to avoid breakage during use or installation.
C. Use only in fixtures rated for lamps wattage and voltage.
D. Lamp operate under high pressure generating intense heat. Prevent contact with liquid and combustible
materials.
September2012
