Quoizel TFNO1714VA Navajo - Manual (Page 3)

Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
3of6
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
, .
. .
STEP 1 Install Nipple with Hex Nuts to
Socket Assembly
-
A. 1/8 G
H G H
Fixture Body F
Thread Hex Nut ( ) onto the short nipple end of
Stem ( ) then thread have Hex Nut ( ) end of Stem ( )
into the Hex Coupling on the top of
( ).
Hand tighten until snug.
Figure 1
Coupling
1/8 Hex Nut
Fixture Body
Assembly Instruction Sheet #IS-TFNO1714VA
For Style TFNO1714VA
2013 QuoizelInc.
Stem
STEP 2 Attach Spacer to Fixture
-
A. Place the Spacer (I) and Check Ring (J) over the Stem
(H). Secure by thread the Knurled Nut (K) onto the
Stem(H). Hand tighten until snug.
Figure 2
Stem
Knurled Nut
Check Ring
Spacer
April2013
