Installation instructions, Step 8 – Quoizel MC842SRC Laguna User Manual
Page 4
INSTALLATION INSTRUCTIONS
STYLE NUMBER: MC842SRC
STEP 8:
a. Place the Diffuser over the end of the Stem, attach to
the Tabs in the bottom edge of the Shade. Pass the
Rubber Washer over the end of the Stem and secure
with the Finial. Hand tighten until snug.
Finial
Rubber Washer
Diffuser
Stem
Your installation is completed now. Restore electricity. Retain this sheet for future reference.
Tab
4 OF 4
