STEP 6 Install Bulb -
A. This fixture uses standard bulb
with medium base . Maximum
100 watts.
B. Insert bulb and screw snugly
into place.
Your fixture is now assembled
and ready to use. Enjoy!
Bulb
Socket
Figure 6
STEP 4 Attach Fixture Body to
Mounting Screw
-
A. Place the Ceiling Canopy (A)
over the Mounting Screws and
secure with Lock Ball (C). Hand
tighten until snug.
Figure 4
C
Mounting Screw
A
STEP 5 Attach Shade to fixture -
A. Place the Diffuser (D) , Rubber
Washer (E) and Flat Washer
(F)over the Center Stem,
secure with the Hex Nut (G).
Hand tighten until sung.
B. Thread the Finial (H) onto the
Center Stem, hand tighten until
sung.
Figure 5
BWL1717CC
PART NUMBER
NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2 "
REPLACEMENT PART DESCRIPTION REQ. NO.
(3) 100W
Bulbs
(Not Supplied)
Medium
Base
1
2
FINISH: COPPER CANYON
GND
11”
6” 5.5”
16” Dia.
17” Dia.
5.5” Dia.
1”
B
D
E
F
G
H
Center Stem
