Quoizel PCSL1616C Platinum Collection Stellar - Manual (Page 2)

2of2
Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
2014 QuoizelInc. January2014
PCSL1616C
PART NUMBER
G3818SH
NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2 "
REPLACEMENT PART DESCRIPTION
ETCHED GLASS SHADE PAINTED WHITE INSIDE
REQ.
1
NO.
(3) 60W
Bulbs
(Not Supplied)
Medium
Base
1
FINISH: POLISHED CHROME
TWO LIGHTS SHOWN FOR ILLUSTRATION PURPOSE ONLY.
STEP 5 - Install Shade
A. Insert the Shade (B) into the fixed Tabs on the side of the Ceiling
Canopy (A) first and then pull the Tab with Spring to secure the
Shade (B).
Your fixture is now assembled and ready to use. Enjoy!
A
B
Figure 5
STEP 4 - Install Bulb
A. This fixture uses standard bulb with medium base. Maximum 60
watts.
B. Insert bulb and screw snugly into place.
Figure 4 Bulb
E. Twist connectors until wires are tightly joined together.
F. Wrap each connection with approved electrical tape and carefully
stuff all the connected wires into the Outlet Box.
16.5” Dia.
3”
4.5”
Tab
Spring
15.5” Dia.
1
