INSTALLATION INSTRUCTIONS
STEP 1:
a Screw the Mounting Screws into the Crossbar place the
Lock Washers over the Mounting Scr ews and thread the
Hex Nuts onto the Mounting Screws as shown
Secur e the
position of the Mounting Screws by tightening the Hex Nuts
against the Crossbar
b Secure the Cr ossbar to the Outlet Box with Outlet Box
Screws
. ,
.
.
.
.
Outlet Box
Crossbar
Mounting Screw
Hex Nut
Outlet Box Screw
Lock Washer
2 OF 3
STYL E NUMBER JS16 15BN :
WHITE OR RIBBED
BLACK OR RED WIRE ( )
F ROM HOUSE
GROUND WIRE GROUND WIRE
F ROM HOUSE F ROM FIXTURE
WHITE OR RIBBED
F ROM FIXTURE F ROM HOUSE
F ROM FIXTURE
BLACK OR SMOOTH
STEP 2 :
* ( )
.
.
. ( )
( )
. ( )
( ) .
.
.
Use Wire Connectors not supplied to connect the
wires
a Connect the House Ground Wire to the Fixtur e Ground
Wire.
b Connect the House White or Ribbed Wire to the
Fixture Supply Wire White or Ribbed Side .
c Connect the House Black or Red Wire to the Fixture
Supply Wire Black or Smooth Side
d Wrap each connection with approved electrical tape and
carefully stuff all of the connected wires into the Outlet
Box
STEP 3:
a. Pass the holes on the Ceiling Canopy over the Mounting
Screws and secure with the Mounting Balls. Hand tighten
until snug.
STEP 4:
a. Screw the beaded end of the Center Stem into the Hex
Coupling underside of the Socket Cluster. Hand tighten
until snug.
Mounting Ball
Mounting Screw
Ceiling
Canopy
Center Stem
Socket
Cluster
Hex Coupling
STEP 5 :
a Install correct bulbs referr ing to fixture markings and or labels for maximum wattage . / .
