Quoizel DH1616AN Duchess User Manual
Package contents, Warnings and cautions, Preparation assembly

PACKAGE CONTENTS
Part
A
E
C
G
B
F
D
H
I
J
K
L
M
Description
Crossbar
Green Ground Screw
Lock Washer
Hex Nut
Nipple
Flat Washer
Rubber Washer
Hex Coupling
Ceiling Canopy
Stem with Hex Nut
Shade
Cap
Finial
Quantity
1pc
2pcs
3pcs
1pc
1pc
2pcs
1pc
1pc
1pc
1pc
1pc
1pc
1pc
A
B
C
D
E
I
J
K
L
M
F
G
H
WARNINGS AND CAUTIONS
!
PREPARATION
ASSEMBLY
INSTRUCTION SHEET IS DH1616
-
STYLE NUMBER DH1616PN,DH1616AN
:
1 OF 3
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,
.
.
.
STEP 1
:
a
Locate the Crossbar and attach it to the Outlet Box
using the Outlet Box Screws
not supplied
b
Locate the Nipple and thread one Hex Nut onto it
about half way. Slip a Lock Washer onto it and thread
one end of the nipple into the center hole of the
Crossbar
c
Position the Ceiling Canopy over the outlet box,
passing the mounting hole in the center of the Ceiling
Canopy over the end of Nipple
d
Adjust the Nipple so approx
3 8
inch of the Nipple
is protruding from the mounting hole. This adjustment
may take a few tries.
e When this length is achieved, remove the Ceiling
Canopy and tighten the Hex Nut up against the
underside of the Crossbar with pliers.
.
.
.
.
.
(
).
.
.
.
/ "
Outlet Box
Outlet Box Screw
Hex Nut
Crossbar
Lock Washer
Nipple
Ceiling Canopy
WARNING:
● Before beginning the installation, turn off electricity at the circuit breaker box or the main fuse box by
switching off the circuit breaker or removing the fuse.
CAUTIONS:
● These instructions are provided for your safety. It is very important that they are read completely before the
installation of your fixture. We strongly recommend that a professional electrician install the fixture.
● Disconnect fixture from the power source before replacing the bulb(s), making sure the bulb(s) had sufficient
time to cool down. DO NOT subject the lamp to any shock while lit as shattering of lamp may result.
● Before beginning installation of product, make sure all parts are present. Compare parts with package
contents list and diagram above. If any part is missing or damaged, do not attempt to assemble, install or
operate the product. Contact customer service for replacement part.
● Estimated Assembly Time: 15
30 minutes
● Tools Required for Assembly (not included): Flathead screwdriver Phillips screwdriver, pliers, electrical
tape, wire cutters, safety glasses &2, 60 Watt, Type A Medium Base Bulbs.
● Helpful Tools (not included): Wire Strippers.
-
,
-
ISSUED 07-2008
Revised 2008 08 28
-
-
