Quoizel TFAV1714VB Ava User Manual
Quoizel Lighting

SPACER TUBE
NIPPLE
SOCKET
HEX COUPLING
CHECK RING
FIXTURE CANOPY
SUPPLY WIRE and GROUND WIRE
STEM with HEX NUT
OUTLET BOX SCREW
not supplied
(
)
UNIVERSAL
CROSSBAR
CHECK RING
SHADE STOP
HEX NUT
FINIAL
SHADE
ASSEMBLY INSTALLATION INSTRUCTIONS
/
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,
.
.
.
IS TFAV1714
Revised 2008 04 17
-
-
-
HEX NUT
1 Before beginning installation
be sure to carefully unpack all parts referring to the
illustration for parts identification
2 With power to the installation point OFF
locate the UNIVERSAL CROSSBAR and
attach to the ceiling mounted OUTLET BOX
Do this using
2 OUTLET BOX
SCREWS not supplied
Locate the STEM with HEX NUT and thread top end into
the center of the UNIVERSAL CROSSBAR
Position the FIXTURE CANOPY over the
outlet box
Pass the mounting hole on the inside deck of the PAN over the end of
STEM with HEX NUT
There should be approx
3 8
of the end of STEM with HEX
NUT protruding from mounting hole on inside deck of FIXTURE CANOPY
If STEM
length is in excess of 3 8
thread STEM further into center of STEM
Remove
FIXTURE CANOPY and snug HEX NUT against underside of UNIVERSAL CROSSBAR
with pliers to secure STEM
3 Thread another HEX NUT onto the other end of the NIPPLE Thread this HEX NUT on
just enough so the inside surface of the PAN rests against it
You may have to trial fit the CEILING CANOPY one more times to insure this distance
also This HEX NUT is needed here to prevent you from crushing down the center of the
CEILING CANOPY
4
Quoizel recommends two people for this step
Position the FIXTURE CANOPY over the OUTLET BOX
Using wire connectors not
supplied connect the HOUSE GROUND WIRE to the FIXTURE GROUND WIRE
connect the HOUSE WHITE WIRE to the FIXTURE SUPPLY WIRE WHITE SIDE
connect the HOUSE BLACK
or RED WIRE to the FIXTURE SUPPLY WIRE BLACK
SIDE
Wrap each connection with approved electrical tape
5 Secure FIXTURE CANOPY to ceiling by aligning and passing mounting hole over end
of STEM secure to UNIVERSAL CROSSBAR
Locate CHECK RING over end of STEM
and thread HEX NUT onto end of STEM
Hand tighten until snug to secure the
FIXTURE CANOPY
Be sure that there are no trapped or pinched wires
6 Install bulbs referring to fixture markings and or labels for maximum wattage
7
Proceed to thread top end of NIPPLE into HEX COUPLING and tighten until snug
Locate SPACER TUBE, CHECK RING and SHADE STOP over end of NIPPLE
Secure
them by threading HEX NUT onto end of NIPPLE
Hand tighten until snug
8 Locate SHADE over end of NIPPLE and thread FINIAL onto end of NIPPLE
Secure it
by threading FINIAL onto end of NIPPLE and hand tighten until snug
9
Restore power to the installation point
Keep this sheet for future reference
.
,
.
.
,
.
( )
(
).
.
.
.
. / "
.
/ ",
.
.
.
(
)
.
(
)
;
(
);
(
)
(
).
.
.
.
.
.
.
.
/
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
*
.
.
Making the connections:
IF IN DOUBT ABOUT ELECTRICAL INSTALLATION,
CONSULT A LICENSED ELECTRICIAN!
