INSTRUCTION SHEET IS-TY1404
STYLE NUMBER: TY1404AN, TY1404WT
ISSUED 07-2010
PACKAGE CONTENTS
PART
DESCRIPTION
QUANTITY
A
Crossbar
1 pc
1 pc
2 pcs
2 pcs
2 pcs
Green Ground Screw
Mounting Screw
Small Hex Nut
Lock Washer
Mounting Ball
Steel Collar
Socket Collar
G9 Bulb
Bulb Shield
B
C
D
E
F
G
H
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,
.
.
.
J
I
K
4 pcs
4 pcs
4 pcs
4 pcs
4 pcs
Shade
2 pcs
A
B
C
D
E
F
G
H
I
J
K
WARNING:
CAUTION:
● Before beginning the installation, turn off electricity at the circuit breaker box or the main fuse box by switching
off the circuit breaker or removing the fuse.
● These instructions are provided for your safety. It is very important that they are read completely before the
installation of your fixture. We strongly recommend that a professional electrician install the fixture.
● Disconnect fixture from the power source before replacing the bulb(s), making sure that bulb(s) had sufficient
time to cool down. DO NOT subject the lamp to any shock while lit as shattering of lamp may result.
● Do not touch the bulb with bare hands use a cloth or glove.
WARNINGS AND CAUTIONS
1 OF 3
PREPARATION
● Before beginning installation of product, make sure all parts are present. Compare parts with package contents
list and diagram above. If any part is missing or damaged, do not attempt to assemble, install or operate the
product. Contact customer service for replacement part.
● Estimated Assembly Time: 20 - 30 minutes
● Tool Required for Assembly (not included): Flathead screwdriver, Phillips screwdriver, Pliers, Electrical tape,
Wire cutter, Safety glasses and (4) 75W Frosted JCD G9 bulbs
● Helpful Tools (not included): Wire strippers.
.
L
M
Socket Collar Tool
Fixture Body
L
M
1 pc
1 pc
REVISED 2011-04-21
