Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
2014 QuoizelInc. April2014
STEP 5 Install Bulb -
A. This fixture uses standard bulb with medium screw base. Maximum 60 watts.
B. Insert bulb and screw snugly into place.
Your fixture is now assembled and ready to use.
Enjoy!
Socket
Bulb
Figure 5
MCRM1507PN
PART NUMBER
NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2"
REPLACEMENT PART DESCRIPTION REQ. NO.
(1) 60W
Bulbs
(Not Supplied)
Medium
Base
1
FINISH: PALLADIAN BRONZE
2
3
S1606MC
9012EXPN
9006EXPN
SHADE MICA 4"D
ROD EXT PALLADIAN BRONZE 12"L X 0.5"D
ROD EXT PALLADIAN BRONZE 6"L X 0.5"D
1
2
2
5 ” Dia.
2
3
1.5 ”
47.5 ”
OVERALL HEIGHT INCLUDES
(2) 6 ” AND 12” RODS
7 ” 7.5”
8.5 ”
4 ” Dia.
7 ” Dia.
1
