Assembly Instruction Sheet #IS-QPP1405C
For Style QPP1405C
STEP 6
- Attach Ceiling Canopy to Mounting
Screw
A. Place the Ceiling Canopy (F) over the Mounting Screws
(B) and secure with Mounting Balls (E). Hand tighten
until snug.
Mounting Screw
Mounting Ball Ceiling Canopy
Figure 7
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
, .
. .
2012 QuoizelInc.
STEP 7 Attach Shade to Socket Assembly
-
A. Place Shade (J) over the Socket, thread the Socket
Collar (K) into the Socket. Hand tighten until snug.
Figure 8
Socket
Collar
Socket
Shade
STEP 8
- Install Bulb
A. This fixture uses standard bulb with a standard screw
base. Maximum 100 watts.
B. Insert bulb and screw properly into place.
Your fixture is now assembled and ready to use.
Enjoy!
Figure 9 Socket
Bulb
October 2012
