INSTALLATION INSTRUCTIONS
Mounting
Screw
Ceiling
Canopy
STEP 5
:
.
a
Place the Ceiling Canopy onto Outlet Box aligning 2
holes in the Ceiling Canopy with 2 Mounting screws
threaded on the Crossbar and secure it against wall
with Mounting Balls
.
STEP 7
:
a
.
Locate the Decorative Shade from the bottom of the fixture
and place the Holders inside of it onto the Bolts on the Mica
Shade Assembly.
STEP 6
:
a Place the Shade over the Socket as shown. Secure by
threading the Socket Collar onto the Socket. Hand tighten
until snug.
.
Outlet Box
Mounting Ball
STEP 8 :
a
Install the correct bulb referring to fixture markings and or labels for maximum wattage
.
/
.
.
.
.
Your installation is completed now
Restore electricity
Retain this sheet for future reference
Socket
Mica Shade
Socket Collar
3 OF 3
STYLE NUMBER MC843PRC
:
Bolt
Mica Shade
Decorative
Shade
Holder
