Quoizel CKMO1509BN Metro User Manual
Page 2
CKMO1509BN
1
2
PART NUMBER
NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2
"
REPLACEMENT PART DESCRIPTION
REQ.
NO.
2of5
GND
2.4mm
13Ga
QUOIZEL
R
6”
12”
(1)100W
Medium Base Bulb
(Not Supplied)
FINISH: BRUSHED NICKEL
3
6” Dia.
1”
51.5”
OVERALL HEIGHT INCLUDES
(2) 6” AND 12” RODS
12.5”
8”
6”
4” Dia.
9” Dia.
11509BNCKMO
9012EXBN
9006EXBN
BASE BRUSHED NICKEL CKMO1509BN
ROD EXT 0.5"D 12"L BRUSHED NICKEL
ROD EXT 0.5"D 6"L BRUSHED NICKEL
1
2
2
4
S1457BE
SHADE BEIGE 9"D, 8"H
1
5
G3462SH
SHADE GLASS OPAL ETCHED 4"D, 6"H
1
1
2
3
4
5
