Quoizel EVE1508PN Eastvale User Manual
Page 2
EVE1508PN
FINISH: PALLADIAN BRONZE
1
PART NUMBER
NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2
"
REPLACEMENT PART DESCRIPTION
REQ.
NO.
2of6
6”
12”
49”
OVERALL HEIGHT INCLUDES
(2) 6” AND 12” RODS
(1)100W Medium
Base Bulb
(Not Supplied)
GND
2.4mm
13Ga
QUOIZEL
R
6” Dia.
1.5”
9.5”
8” Dia.
6”
2
3
4
11508PNEVE
G3477DI
9012EXPN
9006EXPN
BASE
EVE1508PN
PALLADIAN BRONZE
DIFFUSER 7.5"D
ROD EXT 0.5"D, 12"L
PALLADIAN BRONZE
ROD EXT 0.5"D, 6"L
PALLADIAN BRONZE
1
1
2
2
1
2
3
4
