Quoizel DW1506C Downtown User Manual
Package contents, Warnings and cautions, Preparation

INSTRUCTION SHEET IS-DW1506
STYLE NUMBER: DW1506C
REVISED 2014-01-06
PACKAGE CONTENTS
PART
DESCRIPTION
QUANTITY
A
Crossbar
1 pc
1 pc
2 pcs
2 pcs
2 pcs
2 pcs
2 pcs
2 pcs
Green Ground Screw
Mounting Screw
Lock Washer
Hex Nut
Mounting Ball
6” Rod
12” Rod
Ceiling Canopy
B
C
D
E
F
G
H
1 OF 5
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
, .
.
.
J
I
WARNING:
CAUTION:
● Before beginning the installation, turn off electricity at the circuit breaker box or the main fuse box by switching
off the circuit breaker or removing the fuse.
● These instructions are provided for your safety. It is very important that they are read completely before the
installation of your fixture. We strongly recommend that a professional electrician install the fixture.
● Disconnect fixture from the power source before replacing the bulb(s), making sure that bulb(s) had sufficient
time to cool down. DO NOT subject the lamp to any shock while lit as shattering of lamp may result.
WARNINGS AND CAUTIONS
1 pc
1 pc
Socket Assembly
A
B
C
D
E
F
● Before beginning installation of product, make sure all parts are present. Compare parts with package contents
list and diagram above. If any part is missing or damaged, do not attempt to assemble, install or operate the
product. Contact customer service for replacement part.
● Estimated Assembly Time: 20 - 30 minutes
● Tool Required for Assembly (not included): Flathead screwdriver, Phillips screwdriver, Pliers, Electrical tape,
Wire cutter, Safety glasses and (1) 100W A19 medium base bulb
● Helpful Tools (not included): Wire strippers.
.
PREPARATION
I
G
K
M
K
L
1 pc
1 pc
Steel Collar
Shade
H
L
M
1 pc
Socket Collar
J
