INSTALLATION INSTRUCTIONS

3 OF 3

STYLE NUMBER TFIK1508VA,TFCC1508VA

:

WHITE OR RIBBED

BLACK OR RED WIRE

(

)

FROM HOUSE

GROUND WIRE

GROUND WIRE

FROM HOUSE

FROM FIXTURE

WHITE OR RIBBED

FROM FIXTURE

FROM HOUSE

FROM FIXTURE

BLACK OR SMOOTH

STEP 4

:

*

(

)

.

.

.

(

)

(

)

.

(

)

(

).

.

.

Use Wire Connectors not supplied to connect the

wires

a

Connect the House Ground Wire to the Fixture Ground

Wire.

b

Connect the House White

or Ribbed

Wire to the

Fixture Supply Wire White or Ribbed Side .

c Connect the House Black or Red

Wire to the Fixture

Supply Wire Black or Smooth Side

d Wrap each connection with approved electrical tape and

carefully stuff all of the connected wires into the Outlet
Box

Mounting

Screw

Ceiling
Canopy

STEP 5

:

.

a

Place the Ceiling Canopy onto Outlet Box aligning 2

holes in the Ceiling Canopy with 2 Mounting screws
threaded on the Crossbar and secure it against wall
with Mounting Balls

.

STEP 6

:

a

Pass the Shade and the Steel Collar over the Socket as

shown. Secure by threading the Socket Collar onto the
Socket. Hand tighten until snug.

.

Outlet Box

Mounting Ball

STEP 7 :

a

Install the correct bulb referring to fixture markings and or labels for maximum wattage

.

/

.

.

.

.

Your installation is completed now

Restore electricity

Retain this sheet for future reference

Socket

Shade

Steel Collar

Socket Collar
