Quoizel ARL1507PN Ariella User Manual
Page 2
ARL1507PN
1
2
PART NUMBER
NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2
"
REPLACEMENT PART DESCRIPTION
REQ.
NO.
2of5
GND
2.4mm
13Ga
QUOIZEL
R
6”
12”
(1)100W
Medium Base Bulb
(Not Supplied)
FINISH: PALLADIAN BRONZE
3
49”
OVERALL HEIGHT INCLUDES
(2) 6” AND 12” RODS
5” Dia.
1.5”
9.5”
9”
7” Dia.
4
11507PNARL
9006EXPN
9012EXPN
S1484SS
BASE
ARL1507PN
PALLADIAN BRONZE
ROD EXT
6"L X 0.5"D
PALLADIAN BRONZE
ROD
12"L X 0.5"D
PALLADIAN BRONZE
SHADE CAPIZ SHELL 7"D
1
2
2
1
1
2
3
4
