Quoizel VTA5103PN Ventura User Manual
Page 2
VTA5103PN
NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2"
NO.
1
2of7
FINISH:
PALLADIAN BRONZE
M381CHPN
CHAIN PALLADIAN BRONZE 3.8MMX4'
1
PART NUMBER
REPLACEMENT PART DESCRIPTION
REQ.
(3)100W
Medium Base Bulb
(Not Supplied)
NOTE: TWO LIGHTS SHOWN FOR
ILLUSTRATION PURPOSES ONLY.
1
6” Dia.
1”
Overall Height 71.5”
(Includes 48” Chain)
21”
5”
7 5” Dia.
.
23” Dia.
GND
2.4mm
13Ga
QUOIZEL
R
