Quoizel TRG1816OZ Trilogy - Manual (Page 5)

Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
5of7
Assembly Instruction Sheet #IS-TRG1816OZ
For Style TRG1816OZ
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
, .
. .
2014 QuoizelInc. May2014
STEP 6 Assemble Ceiling Canopy
-
A. Push the Ceiling Canopy (H) upward over the Outlet
Box. Thread the Canopy Lock Ring (F) onto the Canopy
Chain Loop (E) and tighten until snug to secure the
Ceiling Canopy (H).
Figure 6
Figure 7
STEP 7 Attach Fixture Chain to Canopy
Chain Loop and Fixture Loop
-
A. Adjust the Fixture Chain (G) to your desired length by
removing the links if needed. You may need to use plier
to open the chain links. If so, put a cloth over the chain
to protect the finish from the pliers.
B. Attach one end of the Fixture Chain (G) onto the
Canopy Chain Loop (E) and then attach the other end of
the Fixture Chain (G) onto the Fixture Loop on the top of
the fixture.
Fixture Loop
Canopy Chain Loop
Fixture Chain
Supply Wire and
Ground Wire
Ceiling Canopy
Canopy Chian Loop
Canopy
Lock Ring
