Installation instructions, Step 7, Step 8 – Quoizel TY5005AN Taylor User Manual
Page 5: Step 9
STYLE NUMBER: TY5005AN, TY5005WT
INSTALLATION INSTRUCTIONS
5 OF 5
STEP 7:
a. Place the Ceiling Canopy over the Mounting Screws
and secure with the Mounting Balls. Hand-tighten until
snug.
Mounting
Screw
Ceiling
Canopy
Outlet Box
Mounting Ball
STEP 8:
a. Place the Shade and the Steel Collar over the Socket
as shown. Secure by threading the Socket Collar onto
the Socket. Hand-tighten until snug.
STEP 9:
a. Install correct bulbs referring to fixture markings and/or labels for maximum wattage.
Your installation is completed now. Restore electricity. Retain this sheet for future reference.
Socket
Shade
Socket Collar
Steel Collar
