CKMO2820BN
1
2
PART NUMBER
NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2"
REPLACEMENT PART DESCRIPTION REQ. NO.
2of6
GND
2.4mm
13Ga
QUOIZEL R
6 ”
12 ”
(3)100W Medium
Base Bulbs
(Not Supplied)
FINISH: BRUSHED NICKEL
3
6 ” Dia.
1 ”
47 ”
OVERALL HEIGHT INCLUDES
(2) 6 ” AND 12” RODS
8 ”
7 ”
20 ” Dia.
12820BNCKMO
G3465DI
9112EXBN
BASE BRUSHED NICKEL CKMO2820BN
DIFFUSER 16.75"D
RODS EXTENSION BRUSHED NICKEL 12"L x 0.58 ”D
1
1
2
4 9106EXBN RODS EXTENSION BRUSHED NICKEL 6 ”L x 0.58”D 2
1
3
4
2
