Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
3of8
STEP 2
- Attach Fixture Loop to Fixture
Assembly
A. Thread the Rod on the Fixture Loop Assembly (I) onto
the Nipple on the top center of the Fixture Assembly
(M). Hand tighten until snug.
Figure 2
Rod
Fixture
Assembly
STEP 1 Adjust Fixture Assembly
-
A. Unfold support arms on fixture assembly to proper
locations.
Figure 1
Assembly Instruction Sheet #IS-LLN5009PN
For Style LLN5009PN
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
, .
. .
Fixture Loop
Assembly
Nipple
