Thank you for purchasing a Quoizel product.

Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700

or visit us on-line at www.quoizel.com

2014 QuoizelInc.

3of8

STEP 2

- Attach Fixture Loop to Fixture

Assembly

A. Thread the Rod on the Fixture Loop Assembly (I) onto

the Nipple on the top center of the Fixture Assembly
(M). Hand tighten until snug.

Figure 2

Rod

Fixture
Assembly

STEP 1

Adjust Fixture Assembly

-

A. Unfold support arms on fixture assembly to proper

locations.

Figure 1

Assembly Instruction Sheet #IS-LLN5005PN

For Style LLN5005PN

6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com

,

.

.

.

Fixture Loop
Assembly

Nipple

August2014
