KY5103IN
PART NUMBER
NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2
"
REPLACEMENT PART DESCRIPTION REQ. NO.
2of6
(3)100W Medium
Base Bulbs
(Not Supplied)
NOTE: TWO LIGHTS SHOWN FOR
ILLUSTRATION PURPOSES ONLY.
1
2
GND 2.4 mm 13 Ga
QU I OZ EL
FINISH: IRON GATE
3
4
15103INKY
9
558KIT
G3327SH
M2353CHIN
BASE KY5103IN
MOUNTING HARDWARE/CANOPY IRON GATE 5.5"D
SHADE WHITE ONYX 6"D X 10"H
SQUARE CHAIN IRON GATE 4MM X 4'
1
1
3
1
10”
6” Dia.
20”Dia.
22”
Overall Height 83.5
(Includes 48 Chain)
"
"
1.5”
5.5” Dia.
